1. 4K UHD screen helps to reproduce every detail clearly.
2. Quantum-dot technology brings purer color and wider color gamut.
3. Contrast ratio of 1200:1 guarantees clear display of every detail.
4. Full lamination + Anti-glare etched glass.

1. Kamvad Pro 16 Plus(4K) can effectively filter out harmful blue light.
2. PW517 that featured PenTech3.0 feels like a traditional drawing instrument.
3. 8192 levels of pressure sensitivity.
4. Dual USB-C ports for easy connections.

• Model
  GT1562


• Appearance
  Color:Dark Grey

  Dimension:402.7 x 257.4 x 13mm

  Workspace:345.6 x 194.4mm

  Net Weight:1.27Kg

  Touch:-

  Stand:Foldable Stand ST200 20°/45°

  Video Interface:USB-C, Full-Featured USB-C


• Screen
  Resolution:3840 x 2160（16:9）UHD

  LCD Type:IPS

  AG Glass:Anti-glare etched glass

  Full Lamination:YES

  Contrast Ratio:1200:1

  Brightness:200cd/m2 (Max.)

  Response Time:25ms

  Viewing Angle:89°/89°(H)/89°/89°(V) (Typ.)(CR＞10)

  Gamut:145% sRGB(Quantum dots)

  Display Color:16.7M(8bit)


• Technical Specifications
  Digital Pen:PW517

  Pen Technology:Battery-Free Electromagnetic Resonance

  Pen Resolution:5080LPI

  Pressure Sensitivity:8192Levels

  Tilt Support:±60°

  Sensing Height:10mm

  Report Rate:＞220PPS

  Accuracy:±0.3mm（center） ±2mm（corner）

  Press Keys:-


• Operating Conditions
  Input Voltage:AC 100-240V, 50/60Hz

  Output Voltage:5V 3A

  Power Consumption:≤15W

  Standby Consumption:≤0.3W

  Working Temp. and Humidity:0-40°C 、 20-80%

  Storage Temp. and Humidity:-20°C~60°C、 10-90%


• OS Compatibility
  Windows 7 or later
  macOS 10.12 or later
  Android（USB3.1 DP1.2）



1 YEAR WARRANTY ON TECHNICAL PROBLEM
